Basement Extension
£2,200.00
Book a Free Site ConsultationWhat’s Included:
- Full structural design and engineering calculations
- Excavation to required depth with geotechnical input (if needed)
- Reinforced concrete walls and floor slab (300mm thick C28/40)
- Steel reinforcement: T12 @ 200mm centres (horizontal and vertical)
- Blinding layer: 100mm C20 concrete
- Waterproofing: 1000-gauge polythene membrane under slab
- Optional 75mm screed with BRC A252 mesh
- 4” drainage outlet with sump pit (optional)
- Precast hollow core slab (roof option available)
2200
Basement Extension
Our basement construction service covers the complete structural package, including excavation, reinforced concrete walls and floors, waterproofing, and sump pit drainage – all engineered for compliance with UK Building Regulations and Eurocodes.
We design and build fully cast in-situ concrete basements suitable for residential extensions, new builds, or retrofit projects. Our standard basement specification includes:
- 300mm thick RC concrete walls and slab (C28/40)
- T12 reinforcement at 200mm centres (horizontal and vertical)
- Blinding layer: 100mm thick C20 concrete
- Waterproofing membrane: 1000-gauge polythene sheet beneath slab
- Optional screed: 75mm with BRC A252 mesh
- Drainage outlet: 4” pipe with optional sump pit provision
- Precast Hollow Core Slab (roof option available on request)
We carry out the full excavation with precision, supported by geotechnical data where needed. The system is designed to handle ground pressure, water ingress, and structural loads — with drawings and calculations signed off by a construction engineer.
| 📐 Technical Specifications | : |
|---|---|
| -Wall Thickness | 300mm reinforced concrete (C28/40) |
| -Base Slab Thickness | 300mm reinforced concrete (C28/40) |
| -Reinforcement | T12 @ 200mm c/c each face (vertical and horizontal) |
| -Blinding Layer | 100mm thick C20 concrete |
| -Waterproofing Layer | 1000 gauge polythene sheet |
| -Optional Screed | 75mm thick with BRC A252 mesh |
| -Construction Method | Fully cast in-situ |
| -Dimensions | Custom per project |
| -Drainage | 4" outlet pipe with sump provision (optional) |
| -Roof Option | Precast Hollow Core Slab (on request) |
